Intel Pentium Gold G6405 4.1GHz 4MB Desktop Processor Boxed Roll over image to zoom in Intel Pentium Gold G6405 4.1GHz 4MB Desktop

Intel Pentium G6405

Product Collection : Intel Pentium Gold Processor Series

Code Name : Products formerly Comet Lake

Vertical Segment : Desktop

Processor Number : G6405

Status : Launched

Launch Date : Q1'21

Lithography : 14 nm

Use Conditions : PC/Client/Tablet

CPU Specifications
 of Cores : 2

 of Threads : 4

Processor Base Frequency : 4.10 GHz

Cache : 4 MB Intel Smart Cache

Bus Speed : 8 GT/s

TDP : 58 W

Supplemental Information
Embedded Options Available : No

Memory Specifications
Max Memory Size (dependent on memory type) : 128 GB

Memory Types : DDR4-2666

Max  of Memory Channels : 2

Max Memory Bandwidth : 41.6 GB/s

Processor Graphics : Intel UHD Graphics 610

Graphics Base Frequency : 350 MHz

Graphics Max Dynamic Frequency : 1.05 GHz

Graphics Video Max Memory : 64 GB

4K Support : Yes, at 60Hz

Max Resolution (HDMI) : 4096x2160 30Hz

Max Resolution (DP) : 4096x2304 60Hz

Max Resolution (eDP - Integrated Flat Panel)‡ : 4096x2304 60Hz

DirectX Support : 12

OpenGL* Support : 4.5

Intel Quick Sync Video : Yes

Intel InTru 3D Technology : Yes

Intel Clear Video HD Technology : Yes

Intel Clear Video Technology : Yes

 of Displays Supported  : 3

Device ID : 0x9BA8

Expansion Options
Scalability
1S Only

PCI Express Revision : 3.0

PCI Express Configurations ‡ : Up to 1x16, 2x8, 1x8+2x4

Max  of PCI Express Lanes : 16

Package Specifications
Sockets Supported
FCLGA1200

Max CPU Configuration : 1

Thermal Solution Specification : PCG 2015C

TJUNCTION : 100°C

Package Size : 37.5mm x 37.5mm

Advanced Technologies
Intel Optane Memory Supported  : Yes

Intel Thermal Velocity Boost : No

Intel Turbo Boost Max Technology 3.0  : No

Intel Turbo Boost Technology  : No

Intel vPro Platform Eligibility  : No

Intel Hyper-Threading Technology  : Yes

Intel Virtualization Technology (VT-x)  : Yes

Intel Virtualization Technology for Directed I/O (VT-d)  : Yes

Intel VT-x with Extended Page Tables (EPT)  : Yes

Intel Transactional Synchronization Extensions : No

Intel 64  : Yes

Instruction Set : 64-bit

Instruction Set Extensions : Intel SSE4.1, Intel SSE4.2

Idle States : Yes

Enhanced Intel SpeedStep Technology : Yes

Thermal Monitoring Technologies : Yes

Intel Identity Protection Technology  : Yes

Intel Stable Image Platform Program (SIPP) : No

Security & Reliability
Intel AES New Instructions : Yes

Secure Key : Yes

Intel Software Guard Extensions (Intel SGX) : Yes with Intel ME

Intel OS Guard : Yes

Intel Trusted Execution Technology :  No

Execute Disable Bit  : Yes

Intel Boot Guard : Yes
