| Category | Specification Details |
|---|---|
| Processor | Intel Core™ i7-14700HX, 20C (8P + 12E) / 28T, P-core 2.1 / 5.5GHz, E-core 1.5 / 3.9GHz, 33MB Intel® Smart Cache |
| AI PC Category | AI-Powered Gaming PC |
| NPU | None |
| Graphics | NVIDIA GeForce RTX™ 5050 8GB GDDR7, Boost Clock 2662MHz, TGP 115W, 440 AI TOPS |
| Chipset | Intel® HM770 Chipset |
| Memory | 1x 16GB SODIMM DDR5-5600 |
| Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
| Max Memory | Up to 32GB DDR5-5600 offering |
| Storage | 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot | Two M.2 2280 PCIe® 4.0 x4 slots |
| Max Storage Support | Up to two drives, 2x M.2 SSD M.2 2242 SSD up to 1TB each |
| Optical | None |
| Card Reader | No Card Reader |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
| Speakers | Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio |
| Microphone | 2x, Array |
| Camera | 5.0MP with E-shutter |
| Battery | 80Wh |
| Power Adapter | 245W Slim Tip (3-pin) |
| Special Features | AI Chip: LA1 |
| Display | 15.1" WQXGA (2560x1600) OLED 1000nits (peak) / 500nits (typical) glossy, 100% DCI-P3, 165Hz, Dolby Vision®, DisplayHDR™ True Black 600 |
| Touchscreen | None |
| Screen-to-Body Ratio | OLED models: 90% AAR (active area ratio) |
| Color Calibration | Factory Color Calibration |
| Pen | Pen Not Supported |
| Keyboard | 24-Zone RGB Backlit, English |
| Touchpad | Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
| Dimensions (WxDxH) | 344.9 x 255.35 x 19.95-21.54 mm (13.58 x 10.05 x 0.79-0.85 inches) |
| Weight | Starting at 1.9 kg (4.19 lbs) |
| Case Color | Eclipse Black |
| Case Material | Aluminium (Top), PC-ABS + 15% Talc (Bottom) |
| Surface Treatment | Aluminium Stamping (Anodized with Sandblasting) |
| Operating System | Windows® 11 Home, English |
| Bundled Software | Office Trial + Lenovo® AI Now |
| WLAN + Bluetooth | Wi-Fi® 7, 802.11be 2x2 + BT5.4 |
| WWAN | WWAN Not Supported |
| Ethernet | 100/1000M (RJ-45) |
| Standard Ports | 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On, 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 95-100W and DisplayPort™ 2.1, 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4, 1x HDMI® 2.1, up to 8K/60Hz, 1x Headphone / microphone combo jack (3.5mm), 1x Ethernet (RJ-45), 1x Slim tip Power connector |
| Docking | Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion 5 15IRX10 |
| Security Chip | Firmware TPM 2.0 Enabled |
| Fingerprint Reader | No Fingerprint Reader |
| Other Security | E-shutter |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | None |
| Bundled Accessories | None |
| Green Certifications | ENERGY STAR® 9.0, EPEAT™ Gold Registered, ErP Lot 6/26, RoHS compliant |
| Other Certifications | TÜV Rheinland® Flicker Free, TÜV Rheinland® Low Blue Light (Hardware Solution) |
| Model | 83LY000MUS |
| Machine Type | 83LY |
| Region | NA |
| Country/Region | USA |
| TopSeller | No |
| EAN / UPC / JAN | 198156401625 |
| Announce Date | 2025-06-24 |
| End of Support | 2057-02-07 |
