Asus ROG Strix Z590-E Gaming WiFi 6E LGA 1200(Intel 11th/10th Gen) ATX Gaming Motherboard (PCIe 4.0, 14+2 Power Stages, DDR4 5333+, Dual Intel 2.5 Gb LAN,Thunderbolt 4, 4xM.2/NVMe SSD and Aura RGB)

Vendor: ASUS
SKU: 90MB1640-M0EAY0
Availability: Out Of Stock
Product Type: Motherboards
8,000.00 EGP
8,000.00 EGP
Limited-Time Offers, End in: 151D 8H 23M 0S

SHIPPING ALL ACROSS EGYPT!

Safe shipping

Estimated to be delivered on 1-5 Working Days .

Enjoy With Compumarts Warranty

Learn More.
Z590-E-Motherboard-Asus-INTEL

Asus ROG Strix Z590-E Gaming WiFi 6E LGA 1200(Intel 11th/10th Gen) ATX Gaming Motherboard (PCIe 4.0, 14+2 Power Stages, DDR4 5333+, Dual Intel 2.5 Gb LAN,Thunderbolt 4, 4xM.2/NVMe SSD and Aura RGB)

8,000.00 EGP

Asus ROG Strix Z590-E Gaming WiFi 6E LGA 1200(Intel 11th/10th Gen) ATX Gaming Motherboard (PCIe 4.0, 14+2 Power Stages, DDR4 5333+, Dual Intel 2.5 Gb LAN,Thunderbolt 4, 4xM.2/NVMe SSD and Aura RGB)

8,000.00 EGP



Asus ROG Strix Z590-E Gaming WiFi 6E LGA 1200(Intel 11th/10th Gen) ATX Gaming Motherboard



  • Ready for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors

  • Optimal Power Solution: 14+2 power stages with ProCool II power connector, high-quality alloy chokes and durable capacitors to support multi-core processors

  • Optimized Thermal Design: VRM and aluminum I/O heatsink, L-shaped heatpipe, four onboard M.2 heatsinks and an M.2 backplate for the PCIe 4.0 M.2 slot

  • High-performance Networking: On-board Intel WiFi 6E AX210 (802.11ax) and dual Intel 2.5 Gb Ethernet with ASUS LANGuard

  • Best Gaming Connectivity: Supports HDMI 2.0 and DisplayPort 1.4 output, four M.2 slots, as well as USB 3.2 Gen 2x2 USB Type-C

  • Intelligent Control: ASUS-exclusive tools AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise Cancelation to simplify setup and improve performance

  • DIY Friendly Design: M.2 Q-Latch, pre-mounted I/O shield, BIOS FlashBack™, Clr CMOS button, Q-Code and FlexKey

  • Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting, including RGB header and Gen 2 addressable headers

  • Industry-leading Gaming Audio: ALC4080 with Savitech SV3H712 amplifier, along with DTS Sound Unbound and Sonic Studio III

  • Renowned Software: Bundled 60 days AIDA64 Extreme subscription and intuitive UEFI BIOS dashboard with integrated MemTest86

1 x HDMI 2.0

1 x DisplayPort 1.4

2 x USB 2.0 ports

Clr CMOS Button

BIOS FlashBack Button

4 x USB 3.2 Gen 1 ports

2 x Intel I225-V 2.5Gb Ethernet

3 x USB 3.2 Gen 2 ports

  • 2 x Type-A + 1 x Type-C

1 x USB 3.2 Gen 2x2 port

Intel Wi-Fi 6E

1 x Optical S/PDIF out

5 x Audio jacks

1 x USB 3.2 Gen 2x2 Type-C port

2 x USB 3.2 Gen 1 ports

6 x SATA 6 Gbps

Thunderbolt header






POWER DESIGN

Digital power control and an array of power stages provide the muscle needed to control the latest Intel CPUs.

TEAMED POWER STAGES

14+2 power stages combine high-side and low-side MOSFETS and drivers into a single package, delivering the power and efficiency that the latest Intel processors demand.

ALLOY CHOKES AND CAPACITORS

Superior chokes and durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards.

PROCOOL II
POWER CONNECTOR

The ASUS ProCool II socket is built to tight specifications to ensure flush contact with the PSU power lines. Metal armor improves heat dissipation, and lower impedance helps prevent hotspots and improves reliability.

DIGI+

POWER CONTROL

The built-in Digi+ voltage-regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth and clean power delivery to the CPU.

SIX-LAYER PCB

CPU

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors

Supports Intel 14 nm CPU

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

 Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset : Intel Z590 Chipset

Memory

DDR4 5333(OC)/5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC) /4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

Dual Channel Memory Architecture

Supports Intel Extreme Memory Profile (XMP)

OptiMem III

 10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.

 11th Gen Intel Core processors support 3200/2933/2800/2666/2400/2133 natively.

Graphics

 Graphics specifications may vary between CPU types.

 Only Intel11th Core processors support DisplayPort 1.4 with max. resolution of 5120 x 2880 60Hz, others will only support DisplayPort 1.4 with max. resolution of 4096 x 2304 60Hz.

 Only Intel 11th Core processors support HDMI 2.0 with max. resolution of 4K 60Hz, others will only support HDMI 1.4 with max. resolution of 4K 30Hz .

Expansion Slots

2 x PCIe 4.0/3.0 x16 (x16, x8/x8, x8/x4) + 1 x PCIe 3.0 x16 (max. x4)

Intel 11th &10th Gen Processors

2 x PCIe 4.0/3.0 x16 slot(s)

- Intel 11th processors support PCIe 4.0 x16 or x8/x8 or x8/x4 mode(s)

- Intel10th processors support PCIe 3.0 x16 or x8/x8 or x8/x4 mode(s)

Intel Z590 Chipset

1 x PCIe 3.0 x16 slot (supports x4 mode)**

 Support PCIe bandwidth bifurcation for RAID on CPU function.

PCIe16_3 shares bandwidth with SATA 56. When PCIe16 3 is populated SATA_56 will be disabled. When PCIe16_3 run at default x2 mode, SATA_56 is enabled.

Multi-GPU Support

Supports NVIDIA 2-Way SLI Technology

Storage

Supports 4 x M.2 slots and 6 x SATA 6Gb/s ports

Intel11th &10th Gen Processors

M.2_1 slot (Key M), type 2242/2260/2280/22110

- Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs

M.2_2 slot (Key M), type 2242/2260/2280/22110

- Intel 11th processors support PCIe 4.0 x4 mode

- Intel 10th processors support PCIe 3.0 x4 mode

Intel Z590 Chipset

M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 mode)

M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)

6 x SATA 6Gb/s ports

Raid function in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.

To enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel Rapid Storage Technology.

When M.2_4 is operating in SATA device, SATA6G_2 will be disabled.


Ethernet

2 x Intel 2.5Gb Ethernet

Wireless & Bluetooth

2x2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2

USB

Rear USB:Total 10 ports

1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C)

3 x USB 3.2 Gen 2 port (2 x Type-A, 1 x USB Type-C)

4 x USB 3.2 Gen 1 port (4 x Type-A)

2 x USB 2.0 port(s) (2 x Type-A)

Front USB:Total 7 ports

1 x USB 3.2 Gen 2x2 connector(s) (suppport(s) USB Type-C)

1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports

2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports

Audio

Audio Features

- SupremeFX Shielding Technology

- ALC4080 + Savitech SV3H712 AMP

- Gold-plated audio jacks

- Rear optical S/PDIF out port

- Premium Japanese audio capacitors

- Audio cover

Back Panel I/O Ports

1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)

3 x USB 3.2 Gen 2 port(s) (2 x Type-A, 1 x USB Type-C )

4 x USB 3.2 Gen 1 port(s) (4 x Type-A)

2 x USB 2.0 port(s) (2 x Type-A)

1 x HDMI port

1 x DisplayPort

1 x Intel Wi-Fi 6E

2 x Intel I225-V 2.5Gb Ethernet

5 x Gold-plated audio jacks

1 x Optical S/PDIF out port

1 x BIOS FlashBack button

1 x Clear CMOS button

Internal I/O Connectors

Fan and Cooling related

1 x 4-pin CPU Fan header(s)

1 x 4-pin CPU OPT Fan header(s)

1 x 4-pin AIO Pump header(s)

3 x 4-pin Chassis Fan header(s)

1 x VRM heatsink Fan header

1 x W_PUMP+ header

Power related

1 x 24-pin Main Power connector

1 x 8-pin +12V Power connector

1 x 4-pin +12V Power connector

Storage related

4 x M.2 slots (Key M)

6 x SATA 6Gb/s ports

USB

1 x USB 3.2 Gen 2x2 connector (support(s) USB Type-C)

1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1

ports

2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports

Miscellaneous

3 x AURA Addressable Gen 2 header(s)

1 x AURA RGB header(s)

1 x CPU Over Voltage jumper

1 x Front Panel Audio header (AAFP)

1 x Q Code

1 x SPI TPM header (14-1pin)

1 x 20-3 pin System Panel header with Chassis intrude function

1 x Thermal Sensor header

1 x Thunderbolt header

Software Features

ROG Exclusive Software

- RAMCache III

- ROG CPU-Z

- GameFirst VI

- Sonic Studio III + Sonic Studio Virtual Mixer

- Sonic Radar III

- DTS Sound Unbound

- Overwolf

- Anti-virus software

ASUS Exclusive Software

Armoury Crate

-AIDA64 Extreme (60 days free trial)

- AURA Creator

- AURA Sync

- Two-Way AI Noise Cancelation

AI Suite 3

- 5-Way Optimization with AI Overclocking

TPU

EPU

DIGI+ VRM

Fan Xpert 4

Turbo app

- EZ update

DAEMON Tools

MyAsus

WinRAR

UEFI BIOS

AI Overclocking Guide

ASUS EZ DIY

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ Mode

FlexKey

MemTest86

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables

4 x SATA 6Gb/s cables

Additional Cooling Kit

1 x Assistant fan (40mm)

1 x Screw package for cooling kit

Miscellaneous

1 x ASUS 2x2 Dual-Band Wi-Fi moving antennas

1 x M.2 Q-Latch package

2 x M.2 Rubber Packages

1 x ROG key chain

1 x cable tie

1 x ROG Graphics card holder

1 x ROG STRIX stickers

1 x ROG STRIX thank you card

Installation Media

1 x Support DVD

Documentation

1 x User manual

Operating System

Windows 10 64bit

Form Factor

ATX

30.5cm x 24.4c
