White Friday Bundle7

White Friday Bundle7

Intel Core i7-13700K Processor 30M Cache, up to 5.40 GHz,16 cores (8 P-cores + 8 E-cores):

• 16 cores (8 P-cores + 8 E-cores) and 24 threads. Integrated Intel UHD Graphics 770 included

• Performance hybrid architecture integrates two core microarchitectures, prioritizing and distributing workloads to optimize performance

• Up to 5.4 GHz unlocked. 30M Cache

• Compatible with Intel 600 series and 700 series chipset-based motherboards

• Turbo Boost Max Technology 3.0, and PCIe 5.0 & 4.0 support. Intel Optane Memory support. No thermal solution included

• Total Cores : 16

• of Performance-cores : 8

• of Efficient-cores : 8

• Total Threads : 24

• Max Turbo Frequency  : 5.40 GHz

• Intel Turbo Boost Max Technology 3.0 Frequency  : 5.40 GHz

• Performance-core Max Turbo Frequency  : 5.30 GHz

• Efficient-core Max Turbo Frequency  : 4.20 GHz

• Performance-core Base Frequency : 3.40 GHz

• Efficient-core Base Frequency : 2.50 GHz

• Cache  : 30 MB Intel Smart Cache

• Total L2 Cache : 24 MB

• Processor Base Power  : 125 W

• Maximum Turbo Power  : 253 W

• Supplemental Information

• Marketing Status : Launched

• Launch Date  : Q4'22

• Embedded Options Available  : No

• Memory Specifications

• Max Memory Size (dependent on memory type) : 128 GB

• Memory Types

• Up to DDR5 5600 MT/s

• Up to DDR4 3200 MT/s

• Max # of Memory Channels : 2

• Max Memory Bandwidth  : 89.6 GB/s

• ECC Memory Supported  : Yes

• Processor Graphics

• Processor Graphics  : Intel UHD Graphics 770

• Graphics Base Frequency : 300 MHz

• Graphics Max Dynamic Frequency : 1.60 GHz

• Graphics Output

• eDP 1.4b, DP 1.4a, HDMI 2.1

• Execution Units : 32

• Max Resolution (HDMI) : 4096 x 2160 @ 60Hz

• Max Resolution (DP) : 7680 x 4320 @ 60Hz

• Max Resolution (eDP - Integrated Flat Panel) : 5120 x 3200 @ 120Hz

• DirectX* Support  : 12

• OpenGL* Support  : 4.5

• OpenCL* Support  : 3.0

• Multi-Format Codec Engines  : 2

• Intel Quick Sync Video : Yes

• Intel Clear Video HD Technology : Yes

• of Displays Supported : 4

• Device ID : 0xA780

• Expansion Options

• Direct Media Interface (DMI) Revision : 4.0

• Max  of DMI Lanes : 8

• Scalability : 1S Only

• PCI Express Revision  : 5.0 and 4.0

• PCI Express Configurations  : Up to 1x16+4, 2x8+4

• Max  of PCI Express Lanes  : 20

• Package Specifications

• Sockets Supported  : FCLGA1700

• Max CPU Configuration

• 1T_JUNCTION

• 100°C

• Advanced Technologies

• Intel Gaussian & Neural Accelerator  : 3.0

• Intel Thread Director : Yes

• Intel Deep Learning Boost (Intel DL Boost)  : Yes

• Intel Speed Shift Technology  : Yes

• Intel Turbo Boost Max Technology 3.0  : Yes

• Intel Turbo Boost Technology   : 2.0

• Intel Hyper-Threading Technology  : Yes

• Intel 64  : Yes

• Instruction Set  : 64-bit

• Instruction Set Extensions

• Intel SSE4.1, Intel SSE4.2, Intel AVX2

• Idle States  : Yes

• Enhanced Intel SpeedStep Technology  : Yes

• Thermal Monitoring Technologies  : Yes

• Intel Volume Management Device (VMD) : Yes

• Security & Reliability

• Intel vPro Eligibility

• Intel vPro Enterprise, Intel vPro Essentials, Intel vPro Platform

• Intel Threat Detection Technology (TDT) : Yes

• Intel Active Management Technology (AMT)  : Yes

• Intel Standard Manageability (ISM)  : Yes

• Intel Remote Platform Erase (RPE) : Yes

• Intel One-Click Recovery : Yes

• Intel Hardware Shield Eligibility  : Yes

• Intel Control-Flow Enforcement Technology  : Yes

• Intel Total Memory Encryption - Multi Key : Yes

• Intel AES New Instructions : Yes

• Secure Key : Yes

• Intel OS Guard : Yes

• Intel Trusted Execution Technology : Yes

• Execute Disable Bit : Yes

• Intel Boot Guard : Yes

• Mode-based Execute Control (MBEC) : Yes

• Intel Stable IT Platform Program (SIPP) : Yes

• Intel Virtualization Technology with Redirect Protection (VT-rp) : Yes

• Intel Virtualization Technology (VT-x) : Yes

• Intel Virtualization Technology for Directed I/O (VT-d) : Yes

• Intel VT-x with Extended Page Tables (EPT) : Yes

ASUS Prime Z790-P WiFi:

• Brand	‎ASUS
  Series	‎Prime
  Item model number	‎Z790-P WIFI D4
  Item Weight	‎3.3 pounds
  Product Dimensions	‎10.8 x 13.4 x 2.8 inches
  Item Dimensions LxWxH	‎10.8 x 13.4 x 2.8 inches
  RAM	‎DDR4
  Memory Speed	‎5333 MHz




  CPU
  Intel Socket LGA1700 for 13 Gen Intel Core Processors & 12 Gen Intel Core, Pentium Gold and Celeron Processors
  Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
   CPU types.

  Chipset

  Intel Z790 Chipset

  Memory

  4 x DIMM, Max. 128GB, DDR4 5333(OC)/5133(OC)/5066(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports Intel Extreme Memory Profile (XMP)
  OptiMem II



  Graphics

  1 x DisplayPort
  1 x HDMI port



  Expansion Slots

  Intel 13 & 12 Gen Processors
  1 x PCIe 5.0 x16 slot
  Intel Z790 Chipset
  3 x PCIe 4.0 x16 slots (support x4 mode)
  1 x PCIe 3.0 x1 slot


  Storage

  Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
  Intel 13 & 12 Gen Processors
  M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
  Intel Z790 Chipset
  M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)
  4 x SATA 6Gb/s ports
  * Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.

  Ethernet

  1 x Realtek 2.5Gb Ethernet

  Wireless & Bluetooth

  Vertical M.2 slot only (Key E, CNVi & PCIe)
  *Wi-Fi module is sold separately.

  USB

  Rear USB (Total 8 ports)
  1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
  1 x USB 3.2 Gen 2 port (1 x Type-A)
  2 x USB 3.2 Gen 1 ports (2 x Type-A)
  4 x USB 2.0 ports (4 x Type-A)
  Front USB (Total 9 ports)
  1 x USB 3.2 Gen 2 connector (supports USB Type-C)
  2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
  * USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.
  * USB_E5 port, USB_E6 port, USB_E7 port and USB_E8 port share the bandwidth.

  Audio

  Realtek 7.1 Surround Sound High Definition Audio CODEC*
  - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - Supports up to 24-Bit/192 kHz playback
  Audio Features
  - Audio Shielding
  - Premium audio capacitors
  - Dedicated audio PCB layers


  Back Panel I/O Ports

  1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
  1 x USB 3.2 Gen 2 port (1 x Type-A)
  2 x USB 3.2 Gen 1 ports (2 x Type-A)
  4 x USB 2.0 ports (4 x Type-A)
  1 x DisplayPort
  1 x HDMI port
  1 x Vertical M.2 slot (Key E)
  1 x Realtek 2.5Gb Ethernet port
  3 x Audio jacks
  1 x PS/2 Keyboard/Mouse combo port

  Internal I/O Connectors

  Fan and Cooling related
  1 x 4-pin CPU Fan header
  1 x 4-pin CPU OPT Fan header
  1 x 4-pin AIO Pump header
  3 x 4-pin Chassis Fan headers
  Power related
  1 x 24-pin Main Power connector
  1 x 8-pin +12V Power connector
  1 x 4-pin +12V Power connector
  Storage related
  3 x M.2 slots (Key M)
  4 x SATA 6Gb/s ports
  USB
  1 x USB 3.2 Gen 2 connector (supports USB Type-C)
  2 x USB 3.2 Gen 1 headers support  4 additional USB 3.2 Gen 1 ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
  Miscellaneous
  3 x Addressable Gen 2 headers
  1 x Aura RGB header
  1 x Clear CMOS header
  1 x COM Port header
  1 x Front Panel Audio header (AAFP)
  1 x S/PDIF Out header
  1 x SPI TPM header (14-1pin)
  1 x 20-5pin System Panel header
  1 x Thunderbolt (USB4) Header

  Special Features

  ASUS 5X PROTECTION III
  - DIGI+ VRM (- Digital power design with DrMOS)
  - LANGuard
  - Overvoltage Protection
  - SafeSlot Core+
  - Stainless-Steel Back I/O
  ASUS Q-Design
  - Q-DIMM
  - Q-Slot
  - Q-LED Core
  ASUS Thermal Solution
  - Flexible M.2 heatsink
  - VRM heatsink design
  ASUS EZ DIY
  - ProCool
  Aura Sync
  - Aura RGB header
  - Addressable Gen 2 headers

  Software Features

  ASUS Exclusive Software
  Armoury Crate
  - Aura Sync
  - Fan Xpert 4 (with AI Cooling II)
  - Power Saving
  AI Suite 3
  -TurboV EVO
  -PC Cleaner
  -DIGI+ VRM
  ASUS CPU-Z
  Norton 360 Deluxe (60 Days Free Trial)
  WinRAR
  UEFI BIOS
  ASUS EZ DIY
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode

  BIOS

  192 (128+64) Mb Flash ROM, UEFI AMI BIOS

  Manageability

  WOL by PME, PXE

  Accessories

  Cables
  2 x SATA 6Gb/s cables
  Miscellaneous
  1 x I/O Shield
  1 x M.2 Rubber Package
  2 x Screw packages for M.2 SSD
  Documentation
  1 x User guide

  Operating System

  Windows 11, Windows 10 64-bit

  Form Factor ATX Form Factor
  12 inch x 9.2 inch ( 30.5 cm x 23.4 cm )
