Flex Bundle #2

Flex Bundle #2

Processor Intel Core i5 12400F

• Intel Core i5-12400F Desktop Processor 6 (6P+0E) Cores Up to 4.4 GHz Turbo Frequency LGA1700 600 Series Chipset 65W Processor Base Power

• This Intel Core i5-12400F Processor offers exceptional performance with 18M Cache and fast speeds of up to 4.40 GHz. Perfect for the latest gaming computers or demanding multitasking tasks. Enjoy a computing experience with greater speed, power, and responsiveness.

  Brand	‎Intel
  Product Dimensions	‎12.7 x 7.62 x 12.7 cm; 470 Grams
  Item model number	‎BX8071512400F
  Manufacturer	‎Intel
  Series	‎Intel 12th Gen Core i5-12400F
  Color	‎Black
  Processor Brand	‎Intel
  Processor Speed	‎4.4 GHz
  Processor Count	‎12
  Wattage	‎65 watts
  Are Batteries Included	‎No
  Item Weight	‎470 g

ASUS PRIME H610M-K D4 ARGB Motherboard

• Intel LGA 1700 Socket: Ready for 14^th, 13^th and 12^th Gen Intel processors

• Ultrafast Connectivity: PCIe 4.0, 32Gbps M.2 slot, Realtek 1 Gb Ethernet and USB 5Gbps support

• Comprehensive Cooling: PCH heatsink and Fan Xpert

• Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers for RGB LED strips, easily synced with Aura Sync-capable hardware

• Two-Way AI Noise Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences

CPU

Intel Socket LGA1700 for Intel Core 14^th & 13^th Gen Processors, Intel Core 12^th Gen, Pentium Gold and Celeron Processors
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset

Intel H610 Chipset

Memory

2 x DIMM slots, max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory
Dual channel memory architecture
Supports Inte Extreme Memory Profile (XMP) memory module
 Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site

Graphics

1 x HDMI port
* Graphics specifications may vary between CPU types
 Supports 4K@60Hz as specified in HDMI 2.1.

Expansion Slots

Intel Core Processors (14^th & 13^th & 12^th Gen)
1 x PCIe 4.0 x16 slot (supports x16 mode)
Intel H610 Chipset
1 x PCIe 3.0 x1 slot
- To ensure compatibility of the device installed

Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel H610 Chipset
M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
4 x SATA 6Gb/s ports

Ethernet

1 x Realtek 1Gb Ethernet

USB

Rear USB (Total 6 ports)
2 x USB 5Gbps ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
Front USB (Total 3 ports)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
1 x USB 2.0 header supports 1 additional USB 2.0 port

Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

Back Panel I/O Ports

2 x USB 5Gbps ports (2 x Type-A)
4 x USB 2.0 ports (4 x Type-A)
1 x HDMI port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 keyboard/mouse combo port

Internal I/O Connectors

Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power Related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage Related
1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
1 x USB 2.0 header supports 1 additional USB 2.0 port
Miscellaneous
2 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x S/PDIF Out header
1 x Speaker header
1 x SPI TPM header (14-1 pin)
1 x 10-1 pin System Panel header

Special Features

ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGuard
- Overvoltage protection
- SafeSlot Core
- Stainless-steel back I/O
ASUS Q-Design
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- Aluminum heatsink design
Aura Sync
- Addressable Gen 2 headers

Software Features

ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert
- Two-Way AI Noise Cancelation
AI Suite 3
- EPU
- DIGI+ VRM
- PC Cleaner
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O shield
1 x M.2 anchor
Documentation
1 x Quick start guide

Operating System

Lexar NM620 M.2 2280 Internal SSD

With speeds of up to 3300MB/s read, enjoy 6x the speed of SATA SSDs3. The NM620 puts you in the computing fast lane and offers impressive performance for demanding creative workstations and gaming experiences.

 Features LDPC for added reliability

Low-Density Parity Check (LDPC) technology makes data transfers more reliable than ever by fixing data errors before they have a chance to slow you down.

Unlike traditional hard disk drives, the NM620 SSD has no moving parts, so it’s built to last. On top of that, it’s also shock and vibration resistant2, making it one robust and reliable SSD.

Efficient

Reduced power consumption and cooler operation makes the battery life last longer than a traditional hard drive

GAMDIAS AURA GC2 Elite Version 2 ARGB 4xFARGB Mid Tower Gaming Case + PSU HELIOS E1-600W 80% Efficiency

• Mesh Front Panel

• Magnetic Dust Filter

• 4 Built-in 120mm Fixed RGB Fans

• Supports up to ATX motherboards

• Tool-Free Installation Tempered Glass Window

• PSU Shroud Included

• Compatible with 340mm GPU

• Meets 80% Efficiency

• 620mm EPS Cable

• Automatic Fan Speed Optimization

• Stealth Black

• Support C6/C7 Power States
