Intel Core i9-12900KS Desktop Processor 16 (8P+8E)

• 14 MB L2 + 30 MB L3 cache memory provides excellent hit rate in short access time enabling improved system performance

• Built-in Intel UHD Graphics 770 controller for great graphics and visual quality

• Brand	‎Intel
  Series	‎Core i9
  Item model number	‎BX8071512900KS
  Item Weight	‎1.01 pounds
  Product Dimensions	‎5.47 x 5.12 x 6.46 inches
  Item Dimensions LxWxH	‎5.47 x 5.12 x 6.46 inches
  Processor Brand	‎Intel
  Processor Count	‎1
  Manufacturer	‎Intel Corporation
  ASIN	‎B09RWL74GY

ASUS TUF Gaming GeForce RTX 4070 Ti 12GB GDDR6X

• Powered by NVIDIA DLSS3, ultra-efficient Ada Lovelace arch, and full ray tracing.

• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering

• 3rd Generation RT Cores: Up to 2X ray tracing performance

• Axial-tech fans scaled up for 21% more airflow

• Dual ball fan bearings last up to twice as long as conventional designs

• Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable

• Metal exoskeleton adds structural rigidity and vents to increase heat reliability

• Auto-Extreme precision automated manufacturing for higher reliability

• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring

Graphic Engine : NVIDIA GeForce RTX 4070 Ti

Engine Clock : OC mode: 2640 MHz

CUDA Core : 7680

Memory Speed : 21 Gbps

Memory Interface : 192-bit

Resolution : Digital Max Resolution 7680 x 4320

Interface

Maximum Display Support : 4

NVlink/ Crossfire Support : No

Accessories

Software

Dimensions

Recommended PSU

Power Connectors

Slot

AURA SYNC

ASUS TUF Gaming Z790-Plus WiFi D4 LGA 1700 (Intel 12th&13th Gen) ATX Gaming Motherboard

Model

TUF GAMING Z790-PLUS WIFI D4

CPU

Intel Socket LGA1700 for 13^th Gen Intel Core Processors & 12^th Gen Intel Core, Pentium Gold and Celeron Processors
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

Chipset

Intel Z790 Chipset

Memory

4 x DIMM, Max. 128GB, DDR4 5333(OC)/5133(OC)/5066(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)
/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
OptiMem II

Graphics

1 x DisplayPort
1 x HDMI port
 Supports max. 4K 60Hz as specified in DisplayPort 1.4.
 Supports 4K 60Hz as specified in HDMI 2.1.
 VGA resolution support depends on processors' or graphic cards' resolution.

Expansion Slots

Intel 13^th & 12^th Gen Processors
1 x PCIe 5.0 x16 slot
Intel Z790 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
1 x PCIe 4.0 x4 slot
2 x PCIe 3.0 x1 slots

Storage

Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
Intel 13^th & 12^th Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110
- Intel 13^th & 12^th Gen processors support PCIe 4.0 x4 mode
Intel Z790 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280/22110  (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
4 x SATA 6Gb/s ports
 Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.

Ethernet

1 x Intel 2.5Gb Ethernet
TUF LANGuard

Wireless & Bluetooth

Wi-Fi 6
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Supports 2.4/5GHz frequency band
Bluetooth v5.2*
The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.

USB

Rear USB (Total 8 ports)
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
Front USB (Total 7 ports)
1 x USB 3.2 Gen 2 connector (supports USB Type-C)
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports

Audio

Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Rear optical S/PDIF out port
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio Cover
* Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.

Back Panel I/O Ports

1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi Module
1 x Intel 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port

Internal I/O Connectors

Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector
Storage related
4 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 2 connector (supports USB Type-C)
1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x 20-3 pin System Panel header with Chassis intrude function
1 x Thunderbolt (USB4) header

Special Features

ASUS TUF PROTECTION
- DIGI+ VRM (- Digital power design with DrMOS)
- ESD Guards
- TUF LANGuard
- Overvoltage Protection
- Safeslot
- Stainless-Steel Back I/O
ASUS Q-Design
- M.2 Q-Latch
- PCIe Slot Q-Release
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- CPU Socket lever protector
- ProCool
- Pre-mounted I/O shield
- SafeDIMM
AURA Sync
- Aura RGB header
- Addressable Gen 2 headers

Software Features

ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Two-Way AI Noise Cancelation
- Power Saving
AI Suite 3
- TurboV EVO
- DIGI+ VRM
- PC Cleaner
TUF GAMING CPU-Z
DTS Audio Processing
MyAsus
Norton 360 for Gamers
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode

BIOS

192 (128+64) Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS Wi-Fi moving antenna
1 x TUF GAMING sticker
2 x M.2 Rubber Packages
1 x Screw package for M.2 SSD
Documentation
1 x TUF Certification card
1 x User guide

Operating System

Lexar NM620 M.2 2280 Internal SSD

With speeds of up to 3300MB/s read, enjoy 6x the speed of SATA SSDs3. The NM620 puts you in the computing fast lane and offers impressive performance for demanding creative workstations and gaming experiences.

 Features LDPC for added reliability

Low-Density Parity Check (LDPC) technology makes data transfers more reliable than ever by fixing data errors before they have a chance to slow you down.

Unlike traditional hard disk drives, the NM620 SSD has no moving parts, so it’s built to last. On top of that, it’s also shock and vibration resistant2, making it one robust and reliable SSD.

Efficient

Reduced power consumption and cooler operation makes the battery life last longer than a traditional hard drive

DeepCool CH510 MESH Digital Mid-Tower ATX PC Case with Digital LCD Display Magnetic Tempered Glass Gaming Case High-Airflow Panels with Front I/O USB Type-C Port for Mini-ITX/Micro-ATX/E-ATX, Black

CH510 MESH DIGITAL

The DeepCool CH510 MESH DIGITAL is a high airflow mid-tower ATX case with great flexibility and wide component compatibility for any system build. Featuring a display screen that is programmable to monitor internal system temperatures for critical information up front.

CH510 MESH DIGITAL

Mid-Tower ATX Case

Evga ATX 700W GD 80 Plus Gold 100-GD-0700-V2 Power Supply

Cooler EVGA CLC 280mm All-In-One RGB LED CPU Liquid

Item Dimensions LxWxH 7 x 14 x 7.7 inches
Brand EVGA
Wattage 125
Cooling Method Water
Compatible Devices Desktop
Noise Level 39.5 dB
Material Copper

The EVGA CLC 280 liquid CPU cooler has arrived This new liquid cooler from EVGA gives you incredible performance, low noise, and robust software controls. The full copper water block pulls the heat from your CPU to the radiator, where newly designed fans, Featuring Teflon Nano bearings, effortlessly disperse the heat. the CLC 280 offers premium sleeved tubing and fully controlled RGB LED to provide a sleek look.

Brand : EVGA
Item model number : 400-HY-CL28-V1
Item Weight : 2.6 pounds
Product Dimensions : 7 x 14 x 7.7 inches
Item Dimensions LxWxH : 7 x 14 x 7.7 inches
Manufacturer: EVGA

Compatible with Intel LGA2066/2011/2011-v3/1200/1150/1151/1155/1156/1366 and AMD AM2/AM3/AM4/FM1/FM2/TR4 and upcoming variants
 280mm Dual Fan radiator. Radiator size: 312mm x 139mm x 27mm (LxWxH) fan Size: 140 x 140 x 25mm (x2)
 Rgb LED's, can be synced to other EVGA RGB components
 Unique EVGA fan design for reducing noise without sacrificing performance
Includes the software suite for monitoring and managing EVGA AIO's, EVGA flow Control. Pump noise level: 20db(a) (Max)

Built To Perform
New cooling block offers improved flowrate and heat transfer surface area for incredible cooling efficiency.
RGB LED
Built in RGB LED gives you full control over the lighting including color cycling, or select your favorite color. The color profiles even save to the firmware!
Sleeved Tubing
Fully sleeved tubing from radiator to CPU block.
