Get ready for some retail magic by offering local pickup or shipping all across Egypt!
BUNDLE # INTEL CORE I5-12400F - PATRIOT VIPER 8G 3200MHZ - P300 256G M.2 NVME SSD - GIGABYTE RTX 3060 8GB GDDR6 GAMING OC
INTEL I5-12400F Processor 18M Cache Up To 4.40 GHz
-
Intel Core i5-12400F Desktop Processor 6 (6P+0E) Cores Up to 4.4 GHz Turbo Frequency LGA1700 600 Series Chipset 65W Processor Base Power
-
This Intel Core i5-12400F Processor offers exceptional performance with 18M Cache and fast speeds of up to 4.40 GHz. Perfect for the latest gaming computers or demanding multitasking tasks. Enjoy a computing experience with greater speed, power, and responsiveness.
Brand
Intel
Product Dimensions
12.7 x 7.62 x 12.7 cm; 470 Grams
Item model number
BX8071512400F
Manufacturer
Intel
Series
Intel 12th Gen Core i5-12400F
Color
Black
Processor Brand
Intel
Processor Speed
4.4 GHz
Processor Count
12
Wattage
65 watts
Are Batteries Included
No
Item Weight
470 g
GIGABYTE GeForce RTX 3060 GAMING OC 8G
NVIDIA Ampere Streaming Multiprocessors
2nd Generation RT Cores
3rd Generation Tensor Cores
Powered by GeForce RTX 3060
Integrated with 8GB GDDR6 128-bit memory interface
WINDFORCE 2X Cooling System with alternate spinning fans
Screen cooling
200 mm compact card size
CORE CLOCK
1807 MHz (Reference Card: 1777 MHz)
NVIDIA AMPERE ARCHITECTURE
The all-new NVIDIA Ampere architecture delivers the ultimate play, featuring advanced 2nd generation Ray Tracing Cores and 3rd generation Tensor Cores with greater throughput.
DIRECTX 12 ULTIMATE Developers
can now add even more amazing graphics effects to Microsoft Windows-based PC games. GeForce RTX graphics cards deliver advanced DX12 features like ray tracing and variable rate shading, bringing games to life with ultra-realistic visual effects and faster frame rates.
WINDFORCE 2X COOLING SYSTEM
The WINDFORCE 2X cooling system features two 90mm unique blade fans, alternate spinning, 3 composite copper heat pipes direct touch GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
The GIGABYTE “Alternate Spinning” is the only solution that can solve the turbulent airflow of adjacent fans. Since the adjacent fans rotate in the same direction, the airflow direction is opposite between the fans, which will cause turbulent airflow and reduce heat dissipation efficiency. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.
ALTERNATE SPINNING
Smooth Airflow : better heat dissipation
STANDARD SPINNING
Turbulent Airflow : worse heat dissipation
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
BUILT STRONG
TINY SIZE WITH MIGHTY PERFORMANCE.
For gamers who prefer a small build with powerful performance, GIGABYTE delivers a compact graphics card with less than 200mm in length. The card provides mighty performance and is easy to install in any small chassis as well.
EXTREME DURABILITY & OVERCLOCKING
The graphics card uses the better power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.
PROTECTION BACK PLATE
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
IN TOTAL COMMAND The interface and functionality of the software is subject to each model.
AORUS ENGINE
The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your game’s requirements.
Graphics Processing : GeForce RTX 3060
-
Core Clock : 1807 MHz (Reference Card: 1777 MHz)
-
CUDA Cores : 3584
-
Memory Clock : 15000 MHz
-
Memory Size : GB
-
Memory Type : GDDR6
-
Memory Bus : 128 bit
-
Memory Bandwidth (GB/sec) : 240 GB/s
-
Card Bus : PCI-E 4.0
-
Digital max resolution : 7680x4320
-
Multi-view : 4
-
Card size : L=198 W=121 H=39 mm
-
PCB Form : ATX
-
DirectX : 12 Ultimate
-
OpenGL : 4.6
-
Recommended PSU ; 550W
-
Power Connectors : 8 pin*1
-
Output :
DisplayPort 1.4a *2
HDMI 2.1 *2
-
SLI Support : N/A
-
Accessories :Quick guide
* The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
MSI PRO H610M-E DDR4 Motherboard
Brand |
MSI |
|---|---|
Manufacturer |
MSI, Micro-Star INT'L CO., LTD. No.69, Lide St., Zhonghe Dist., New Taipei City 235, Taiwan |
Item Height |
28 Centimeters |
Item Width |
50 Centimeters |
Product Dimensions |
50 x 50 x 28 cm; 193 Grams |
Item model number |
245569A1 |
Processor Socket |
LGA 1700 |
Memory Technology |
DDR4 |
Maximum Memory Supported |
64 GB |
Memory Clock Speed |
3200 MHz |
Graphics Card Interface |
Integrated |
Are Batteries Included |
No |
Manufacturer |
MSI |
Country of Origin |
Malaysia |
Item Weight |
193 g |
Brand |
MSI |
|---|---|
Model |
PRO H610M-E DDR4 |
CPU Socket Type |
LGA 1700* Dedicated LGA1700 mounting bracket is required. |
|---|---|
CPU Type |
Supports 13th / 12th Gen Intel Core, Pentium Gold, Celeron Processors |
Chipset |
Intel H610 |
|---|
Onboard Video Chipset |
Supported only by CPU with integrated graphic |
|---|
Number of Memory Slots |
2x288pin (DDR4) |
|---|---|
Memory Standard |
DDR4 3200 |
Maximum Memory Supported |
64GB |
Channel Supported |
Dual Channel |
PCI Express 4.0 x16 |
1 x PCI Express 4.0 x16 |
|---|---|
PCI Express x1 |
1 x PCI Express 3.0 x1 |
SATA 6Gb/s |
4 x SATA 6Gb/s |
|---|---|
M.2 |
1 x M.2 Gen3 x4 32 Gbps slot |
Audio Chipset |
Realtek ALC897 |
|---|---|
Audio Channels |
7.1 Channels |
LAN Chipset |
Intel I219-V |
|---|---|
Max LAN Speed |
10/100/1000Mbps |
Back I/O Ports |
1 x HDMI1 x LAN (RJ45)3 x Audio Jacks1 x PS/2 Keyboard/Mouse Combo2 x USB 3.2 Gen 1 Type-A4 x USB 2.0/1.1 |
|---|
Form Factor |
Micro ATX |
|---|---|
LED Lighting |
RGB |
RAM PATRIOT VIPER STEEL 3200Mhz
Patriot’s Viper Steel memory modules are designed with true performance in mind. Built for the latest Intel and AMD platforms, our Viper Steel DDR4 memory provides the best performance and stability for the most demanding computer environments
-
Capacity: DDR4 8GB Single Module
-
Base Frequency: PC4-17000 (2133MHz); Tested Frequency Profile 1: PC4-25600 (3200MHz)
-
Base Timings: 15-15-15-36; Tested Timings: 16-18-18-36
-
COMPATIBILITY: Tested on the latest Intel & AMD platforms
-
Custom design and series: All aluminum heat shield featuring gunmetal grey sides with diamond- cut viper logo and black top.
-
Aluminum heat spreader with unique and specific design element
-
Feature Overclock: XMP 2.0 Support for Automatic Overclocking
-
Compatibility: Tested across the latest Intel and AMD platforms for reliable and fast performance
-
Format: NON-ECC Unbuffered DIMM; Pin Out: 288-Pin
-
Patriot P300 256G M.2 PCIe Gen 3 X4 Low-Power Consumption SSD
The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P300 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives.
Brand |
Patriot |
Model |
P300 NVMe |
FEATURES |
Built with the latest PCIe 3 x 4 controller |
2280 m.2 PCIe NVMe Gen3 x 4 SSD |
|
NANDXtend ECC Technology |
|
HMB Technology |
|
Operating Temperature: 0~70°C |
|
TBW |
320TB |
O/S Supported |
Windows 7*/8*/8.1/10 |
Deepcool MATREXX 40 3FS +DEEPCOOL PF650 650 Watt 80 Plus
-
Black, Mid-Tower, 400mm×215mm×431mm(L×W×H), ABS+SPCC+Tempered Glass
-
3.5″ Drive Bays x 2 , 2.5″ Drive Bays x 2, 4 Expansion Slots
-
I/O Ports : USB3.0×1、USB2.0×1、Audio×1
-
Pre-installed: Rear: 1×120mm LED fan; Front:120mm×2 LED fan;Optional: Front: 120mm×3/140mm×2 Top: 120mm×2/140mm×2
-
Liquid Cooler Compatibility : Front: 120/140/240/280; TOP: 120/140/240/280 Rear: 120
MATREXX 40 3FS
ESSENTIAL MICRO-ATX
The MATREXX 40 3FS Micro-ATX case packs massive value in a tiny chassis with impressive cooling support for max airflow, three tri-color LED fans and a solid tempered glass panel.
SUBSTANTIAL COOLING CAPABILITY
With support for up to six 120mm or four 140mm cooling fans and also radiators up to 280mm installed on top or in front, the MATREXX 40 3FS provides ample cooling configurations.
THREE TRI-COLOR LED FANS
Three 120mm fans come pre-installed in the MATREXX 40 3FS with two at front and one at back. The fans are lit up with a preset tri-color LED combination, simply plug in the power and enjoy the visual experience.
BETTER AIRFLOW
The front and top mesh panels provide optimal ventilation to move large amounts of air throughout the case.
TEMPERED GLASS SIDE PANEL
Upgrade the quality of your build with a clean edge-to-edge tempered glass panel.
GREAT CLEARANCE
Technical Spec
Motherboards |
Mini-ITX / Micro-ATX |
Case Type |
MATX Case |
Product Dimensions |
400mm×215mm×431mm(L×W×H) |
Carton Dimensions |
470mm×288mm×470mm(L×W×H) |
Net Weight |
5.52KG |
Gross Weight |
6.42kg |
Colors |
Black |
Materials |
ABS+SPCC+Tempered Glass |
3.5" Drive Bays |
2 |
2.5" Drive Bays |
2 |
External 3.5'' Drive Bays |
0 |
5.25" Drive Bays |
0 |
Power Supply Type |
ATX PS2 （maximum length: 160mm） |
I/O Ports |
USB3.0×1、USB2.0×1、Audio×1 |
Expansion Slots |
4 Slots |
Cooling Fans Compatibility |
Pre-installed: Rear: 1×120mm LED fan; Front:120mm×2 LED fan;Optional: Front: 120mm×3/140mm×2 Top: 120mm×2/140mm×2 |
Liquid Cooler Compatibility |
Front: 120/140/240/280; TOP: 120/140/240/280 Rear: 120； |
CPU Cooler Height Limit |
165mm |
VGA Length Limit |
320mm |
Cable Management |
20mm clearance |
EAN Code |
6933412714569 |
PN Code |
DP-MATX-MATREXX40-3FS |
