Intel H510M H Ultra Durable Motherboard with 6+2 Phases Digital VRM, PCIe 4.0 Design, Realtek GbE LAN, Anti-Sulfur Resistor,  Smart Fan 6

Cooling Features

  • High Current Support

    Each fan headers support PWM and DC fan and Water cooling Pump , and up to 24W (12V x 2A) with Over-Current Protection

  • Precision Control

    Up to 7 temperature/fan speed control points for precise fan curve

  • Dual Curve Mode

    Slope/Stair dual mode for different user scenario

  • Fan Stop

    Fan can stop completely below users' specified temperature point


  • Supports 11th and 10th Gen Intel  Core Series Processors

  • Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs

  • Ultra-Fast M.2 with PCIe Gen3 X4 & SATA Interface

  • Realtek GbE LAN with Bandwidth Management

  • High Quality Audio Capacitors and Audio Noise

  • Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP

  • GIGABYTE APP Center, Simple and Easy Use

  • Anti-Sulfur Resistors Design

  • CPU

    LGA1200 package:

    1. 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors

    2. 10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors

    3. L3 cache varies with CPU

    Chipset

    1. Intel H510 Express Chipset

  • Memory

    1. 11th Generation Intel Core i9/i7/i5 processors:

      Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules

    2. 10th Generation Intel Core i9/i7 processors:

      Support for DDR4 2933/2666/2400/2133 MHz memory modules

    3. 10th Generation Intel Core i5/i3/Pentium/Celeron processors:

      Support for DDR4 2666/2400/2133 MHz memory modules

    4. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory

    5. Dual channel memory architecture

    6. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

    7. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

    8. Support for Extreme Memory Profile (XMP) memory modules

    Onboard Graphics

  • Integrated Graphics Processor-Intel  HD Graphics support:

    1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200 60 Hz

    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160 30 Hz

       Support for HDMI 1.4 version and HDCP 2.3.

    Audio

    1. Realtek Audio CODEC

    2. High Definition Audio

    3. 2/4/5.1/7.1-channel

       To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.

  • LAN

    1. Realtek GbE LAN chip (10/100/1000 Mbit)

  • Expansion Slots

    1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)

      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

      (The PCIEX16 slot conforms to PCI Express 4.0 standard.)*

      Supported by 11th Generation processors only.

    2. 1 x PCI Express x1 slot (PCIEX1)

      (The PCIEX1 slot conforms to PCI Express 3.0 standard.)

  • Storage Interface

    Chipset:

    1. 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)

    2. 4 x SATA 6Gb/s connectors


  • USB

    Chipset:

    1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

    2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector

    2. 1 x 8-pin ATX 12V power connector

    3. 1 x CPU fan header

    4. 1 x system fan header

    5. 1 x RGB LED strip header

    6. 1 x M.2 Socket 3 connector

    7. 4 x SATA 6Gb/s connectors

    8. 1 x front panel header

    9. 1 x front panel audio header

    10. 1 x USB 3.2 Gen 1 header

    11. 1 x USB 2.0/1.1 header

    12. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

    13. 1 x serial port header

    14. 1 x Clear CMOS jumper

    All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V  24W.

  • Back Panel Connectors

    1. 1 x PS/2 keyboard/mouse port

    2. 1 x D-Sub port

    3. 1 x HDMI port

    4. 2 x USB 3.2 Gen 1 ports

    5. 4 x USB 2.0/1.1 ports

    6. 1 x RJ-45 port

    7. 3 x audio jacks

  • I/O Controller

    1. iTE I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection

    2. Temperature detection

    3. Fan speed detection

    4. Fan fail warning

    5. Fan speed control

      Whether the fan speed control function is supported will depend on the cooler you install.

  • BIOS

    1. 1 x 256 Mbit flash

    2. Use of licensed AMI UEFI BIOS

    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for APP Center

       Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

      Ambient LED

      EasyTune

      Fast Boot

      ON/OFF Charge

      Smart Backup

      System Information Viewer

    2. Support for Q-Flash

    3. Support for Xpress Install

  • Bundled Software

    1. Norton Internet Security (OEM version)

    2. LAN bandwidth management software

  • Operating System

    1. Support for Windows 10 64-bit

  • Form Factor

    1. Micro ATX Form Factor; 24.4cm x 21.0cm

Intel H510M H Ultra Durable Motherboard with 6+2 Phases Digital VRM, PCIe 4.0 Design, Realtek GbE LAN, Anti-Sulfur Resistor, Smart Fan 6
