PERFORMANCE
Processor
Intel Core Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB
AI PC Category
AI-Powered Gaming PC
NPU
Integrated Intel AI Boost, up to 13 TOPS
Graphics
NVIDIA GeForce RTX 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 105W, 572 AI TOPS
Chipset
Intel® HM870 Chipset
Memory
2x 16GB SO-DIMM DDR5-5600
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 32GB DDR5-5600 offering
Storage
1TB SSD M.2 2242 PCIe 4.0x4 NVMe
Storage Slot
Two M.2 2280 PCIe 4.0 x4 slots
Max Storage Support
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
Optical
None
Card Reader
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3306 codec
Speakers
Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Microphone
2x, Array
Camera
5.0MP with E-shutter
Battery
80Wh
Power Adapter
245W Slim Tip (3-pin)
Special Features
AI Chip: LA3
DESIGN
Display
16" WQXGA (2560x1600) IPS 500nits Anti-glare, 100% DCI-P3, 240Hz, DisplayHDR 400, Dolby Vision, G-SYNC, Low Blue Light, High Gaming Performance
Touchscreen
None
Screen-to-Body Ratio
91.7% AAR (active area ratio)
Color Calibration
Factory Color Calibration
Pen
Pen Not Supported
Keyboard
24-Zone RGB Backlit, English
Touchpad
Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH)
364.38 x 268.06 x 21.69-25.95 mm (14.35 x 10.55 x 0.85-1.02 inches)
Weight
Around 2.45 kg (5.4 lbs)
Case Color
Storm Grey
Case Material
Aluminium (Top), PC-ABS (Bottom)
Surface Treatment
Anodizing Sandblasting
SOFTWARE
Operating System
Windows 11 Home, English
Bundled Software
Office Trial + Lenovo AI Now
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi 7, 802.11be 2x2 + BT5.4
WWAN
Non-WWAN
Ethernet
100/1000M (RJ-45)
Standard Ports
2x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort 2.1
1x USB-C (Thunderbolt 4 / USB4 40Gbps), with DisplayPort 2.1 1x HDMI 2.1, up to 8K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x Power connector
Docking
Various docking solutions supported via Thunderbolt or USB-C.
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR 8.0 ErP Lot 6/26 RoHS compliant
Other Certifications
TÜV Rheinland High Gaming Performance TÜV Rheinland Low Blue Light (Hardware Solution)
MODEL INFORMATION
Model
83NX0000US
Machine Type
83NX
Region
NA
Country/Region
USA
TopSeller
No
EAN / UPC / JAN
198156894557
Announce Date
2025-05-19
End of Support
2031-06-09
