LENOVO LOQ 15IRX10 83JE00DAED Core i7-14700HX 20 Cores – 24GB DDR5 5600 – 512GB SSD – RTX 5050 8GB GDDR7 – 15.6″ FHD IPS 100% sRGB 144Hz G-SYNC – Win 11 - 2Y Warranty

LENOVO LOQ 15IRX10 83JE00DAED Core i7-14700HX 20 Cores – 24GB DDR5 5600 – 512GB SSD – RTX 5050 8GB GDDR7 – 15.6″ FHD IPS 100% sRGB 144Hz G-SYNC – Win 11 -2 years warranty

PERFORMANCE

Processor:

Intel Core i7-14700HX, 20C (8P + 12E) / 28T, P-core 2.1 / 5.5GHz, E-core 1.5 / 3.9GHz, 33MB

AI PC Category:

AI-Powered Gaming PC

Graphics:

NVIDIA GeForce RTX 5050 8GB GDDR7, Boost Clock 2370MHz, TGP 100W, 440 AI TOPS

Chipset:

Intel HM770 Chipset

Memory:

2x 12GB SO-DIMM DDR5-4800

Memory Slots:

Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory:

Up to 32GB DDR5-4800 offering

Storage:

512GB SSD M.2 2242 PCIe 4.0x4 NVMe

Max Storage Support:

Up to two drives, 2x M.2 SSD

• M.2 2242 SSD up to 1TB each

Storage Slot:

Two M.2 2280 PCIe 4.0 x4 slots

Card Reader:

None

Optical:

None

Audio Chip:

High Definition (HD) Audio, Realtek ALC3287 codec

Speakers:

Stereo speakers, 2W x2, optimized with Nahimic Audio

Camera:

5.0MP with E-shutter

Microphone:

2x, Array

Battery:

60Wh

Power Adapter:

170W Slim Tip (3-pin)

Special Features:

AI Chip: LA1

DESIGN

Display:

15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC

Touchscreen:

None

Color Calibration:

None

Keyboard:

White Backlit, Arabic

Touchpad:

Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Case Color:

Luna Grey

Surface Treatment:

Painting

Case Material:

PC-ABS (Top), PC-ABS (Bottom)

Pen:

Pen Not Supported

Dimensions (WxDxH):

359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)

Weight:

Starting at 2.4 kg (5.29 lbs)

SOFTWARE

Operating System:

Windows 11 Home Single Language, Arabic / English

Bundled Software:

Office Trial

CONNECTIVITY

WLAN + Bluetooth:

Wi-Fi 6, 802.11ax 2x2 + BT5.2

WWAN:

Non-WWAN

Ethernet:

100/1000M (RJ-45)

Standard Ports:

3x USB-A (USB 5Gbps / USB 3.2 Gen 1)

1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort 1.4

1x HDMI 2.1, up to 8K/60Hz

1x Headphone / microphone combo jack (3.5mm)

1x Ethernet (RJ-45)

1x Power connector

Docking:

Various docking solutions supported via USB-C

SECURITY & PRIVACY

Security Chip:

Firmware TPM 2.0 Enabled

Fingerprint Reader:

None

Other Security:

E-shutter

SERVICE

Base Warranty:

1-year, Courier or Carry-in

Included Upgrade:

2Y Courier/Carry-in upgrade from 1Y Courier/Carry-in

(2Y Warranty)

ACCESSORIES

Bundled Accessories:

None

CERTIFICATIONS

Green Certifications:

ErP Lot 6/26, RoHS compliant

Other Certifications:

TÜV Rheinland Low Blue Light (Software Solution)

MODEL INFORMATION

Model: 83JE00DAED

Machine Type: 83JE
