MSI MAG B660M Bazooka DDR4 Motherboard

Vendor: MSI
SKU: 4526541041075
Availability: In Stock
Product Type: Motherboards
10,499.00 EGP
0.00 EGP
10,499.00 EGP
Save -10,499.00 EGP
Limited-Time Offers, End in: 151D 8H 23M 0S

SHIPPING ALL ACROSS EGYPT!

Safe shipping

Estimated to be delivered on 1-5 Working Days .

Enjoy With Compumarts Warranty

Learn More.
MAG -B660M-MSI-Bazooka-DDR4

MSI MAG B660M Bazooka DDR4 Motherboard

0.00 EGP 10,499.00 EGP

MSI MAG B660M Bazooka DDR4 Motherboard

0.00 EGP 10,499.00 EGP



MSI MAG B660M Bazooka DDR4 Motherboad

MSI MB



LIGHTNING GEN 4 M.2

Utilizing 12th Gen Intel Core processors, MSI B660 motherboards feature latest Lightning Gen 4 M.2 which is the fastest onboard storage solution on the market with up to 64 Gb/s transfer speed.

B550 CARBON

HIGH-BANDWIDTH AND LOW-LATENCY NETWORK 2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.

  • Supports 12th/ 13th Gen Intel Core, Pentium Gold and Celeron processors for LGA 1700 socket

  • Supports DDR4 Memory, up to 4800+(OC) MHz

  • Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works

  • Latest Network Solution: Onboard 2.5G LAN plus Gigabit LAN with LAN Manager deliver the best online experience without lag

  • Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs

  • Audio Boost: Reward your ears with studio grade sound quality

  • Multi-GPU: With Steel armor PCIe slots. Supports AMD Crossfire

PROCESSOR

  • Supports 12th/ 13th Gen Intel Core Processors

  • Processor socket LGA1700

CHIPSET Intel B660 Chipset MEMORY

  • 4x DDR4 memory slots, support up to 128GB

  • Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)

  • Max overclocking frequency:

  • 1DPC 1R Max speed up to 5333+ MHz

  • 1DPC 2R Max speed up to 4000+ MHz

  • 2DPC 1R Max speed up to 4000+ MHz

  • 2DPC 2R Max speed up to 3600+ MHz

  • Supports Dual-Channel mode

  • Supports non-ECC, un-buffered memory

  • Supports Intel Extreme Memory Profile (XMP)

EXPANSION SLOT

  • 2x PCIe x16 slots

  • PCI_E1 slot (From CPU)

  • Supports PCIe 4.0 x16

  • PCI_E3 slot (From B660 Chipset)

  • Supports PCIe 3.0 x4

  • 1x PCIe 3.0 x1 slot (From B660 chipset)

MULTI-GPU

  • Supports 2-Way AMD Cross Fire Technology

ONBOARD GRAPHICS

  • 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz

  • 1x DisplayPort 1.4 port with HBR3, supports a maximum resolution of 4K 60Hz

  1. Available only on processors featuring integrated graphics.

  2. Graphics specifications may vary depending on the CPU installed.

STORAGE

  • 4x SATA 6Gb/s ports (SATA5~8, from B660 Chipset)

  • 2x M.2 slots (Key M)

  • M2_1 slot (From CPU)

  • Supports PCIe 4.0 x4

  • Supports 2242/ 2260/ 2280 storage devices

  • M2_2 slot (From B660 Chipset)

  • Supports PCIe 4.0 x4

  • Supports SATA 6Gb/s

  • Supports 2242/ 2260/ 2280 storage devices

  • Supports Intel Optane Memory

  • Supports Intel Smart Response Technology for Intel Core processors

  1. SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

RAID

  • Supports RAID 0, RAID 1 , RAID 5 and RAID 10 for SATA storage devices

USB

Intel B660 Chipset

  • 2x USB 3.2 Gen 2 10Gbps Type-A ports on the back panel

  • 3x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 1 Type-C available through the internal connector)

  • 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 Type-A ports available through the internal connectors)

Asmedia ASM1074 : 2x USB 3.2 Gen 1 5Gbps Type-A ports through the internal connector

AUDIO Realtek ALC897 Codec : 7.1-Channel High Definition Audio LAN : 1x Realtek 8125BG 2.5Gbps LAN controller INTERNAL CONNECTORS

  • 1x 24-pin ATX main power connector

  • 1x 8-pin ATX 12V power connector

  • 1x 4-pin ATX 12V power connector

  • 4x SATA 6Gb/s connectors

  • 2x M.2 slots (M-Key)

  • 1x USB 3.2 Gen 1 5Gbps Type-C port

  • 1x USB 3.2 Gen 1 5Gbps Type-A connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)

  • 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

  • 1x 4-pin CPU fan connector

  • 1x 4-pin water-pump fan connector

  • 2x 4-pin system fan connectors

  • 1x Front panel audio connector

  • 2x System panel connectors

  • 1x Chassis Intrusion connector

  • 1x TPM module connector

  • 1x Clear CMOS jumper

  • 1x TBT connector (supports RTD3)

  • 1x Serial port

  • 1x Tuning Controller connector

LED FEATURE

  • 1x 4-pin RGB LED connector

  • 2x 3-pin RAINBOW LED connectors

  • 4x EZ Debug LED

BACK PANEL PORTS

  1. Keyboard / Mouse

  2. DisplayPort

  3. 2.5G LAN

  4. Audio Connectors

  5. USB 2.0

  6. HDMI

  7. USB 3.2 Gen 1 5Gbps Type-A

  8. USB 3.2 Gen 2 10Gbps Type-A
